Spring Cloud Zuul MySQL 实现动态路由以及手动刷新

介绍

实现zuul的动态路由可通过两种方式

1. 基于配置中心实现配置文件动态刷新
2. 基于数据库存储配置文件，发布RoutesRefreshedEvent事件，触发SimpleRouteLocator重新加载配置

代码参考：https://github.com/iyezhou/zuul-gateway-demo

实现步骤

数据库初始化

CREATE TABLE `zuul_route` (
  `id` varchar(50) NOT NULL,
  `path` varchar(255) NOT NULL,
  `service_id` varchar(50) DEFAULT NULL,
  `url` varchar(255) DEFAULT NULL,
  `strip_prefix` tinyint(1) DEFAULT '1',
  `retryable` tinyint(1) DEFAULT '0',
  `enabled` tinyint(1) NOT NULL DEFAULT '1',
  `description` varchar(255) DEFAULT NULL,
  PRIMARY KEY (`id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8;
insert into `zuul_route`(`id`,`path`,`service_id`,`url`,`strip_prefix`,`retryable`,`enabled`,`description`) values ('pppp','/client/**',NULL,'http://localhost:7070',1,0,1,'url');

配置文件

server:
  port: 8080
eureka:
  client:
    serviceUrl:
      defaultZone: http://127.0.0.1:8000/eureka/   #注册中心地址
    registry-fetch-interval-seconds: 15    #客户端拉取服务端的频率
spring:
  application:
    name: zuul
  datasource:
    url: jdbc:mysql://rm-bp1e5s5co.mysql.rds.aliyuncs.com:3306/zuul?useUnicode=true&characterEncoding=utf-8
    driver-class-name: com.mysql.jdbc.Driver
    username: rook
    password: Hou5
ribbon:
  eureka:
    enabled: true

数据库访问

public class ZuulRouteEntity {

    private String id;

    private String path;

    private String serviceId;

    private String url;

    private boolean stripPrefix = true;

    private Boolean retryable;

    private Boolean enabled;

    private String description;
}

@Component
public class PropertiesDao {

    @Autowired
    private JdbcTemplate jdbcTemplate;

    private final static String SQL = "SELECT * FROM zuul_route WHERE enabled = TRUE";

    public Map<String, ZuulRoute> getProperties() {
        Map<String, ZuulRoute> routes = new LinkedHashMap<>();
        List<ZuulRouteEntity> list = jdbcTemplate.query(SQL, new BeanPropertyRowMapper<>(ZuulRouteEntity.class));
        list.forEach(entity -> {
            if (StringUtils.isEmpty(entity.getPath())) {
                return;
            }
            ZuulRoute zuulRoute = new ZuulRoute();
            BeanUtils.copyProperties(entity, zuulRoute);
            routes.put(zuulRoute.getPath(), zuulRoute);
        });
        return routes;
    }
}

重写理由配置加载方法

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.cloud.netflix.zuul.filters.RefreshableRouteLocator;
import org.springframework.cloud.netflix.zuul.filters.SimpleRouteLocator;
import org.springframework.cloud.netflix.zuul.filters.ZuulProperties;
import org.springframework.cloud.netflix.zuul.filters.ZuulProperties.ZuulRoute;
import org.springframework.util.StringUtils;

import java.util.LinkedHashMap;
import java.util.Map;

public class DynamicZuulRouteLocator extends SimpleRouteLocator implements RefreshableRouteLocator {

    @Autowired
    private ZuulProperties properties;

    @Autowired
    private PropertiesDao propertiesDao;

    public DynamicZuulRouteLocator(String servletPath, ZuulProperties properties) {
        super(servletPath, properties);
        this.properties = properties;
    }

    @Override
    public void refresh() {
        doRefresh();
    }

    @Override
    protected Map<String, ZuulRoute> locateRoutes() {
        LinkedHashMap<String, ZuulRoute> routesMap = new LinkedHashMap<>();
        routesMap.putAll(super.locateRoutes());
        routesMap.putAll(propertiesDao.getProperties());
        LinkedHashMap<String, ZuulRoute> values = new LinkedHashMap<>();
        routesMap.forEach((key, value) -> {
            String path = key;
            if (!path.startsWith("/")) {
                path = "/" + path;
            }
            if (StringUtils.hasText(this.properties.getPrefix())) {
                path = this.properties.getPrefix() + path;
                if (!path.startsWith("/")) {
                    path = "/" + path;
                }
            }
            values.put(path, value);
        });
        return values;
    }
}

@Configuration
public class DynamicZuulConfig {

    @Autowired
    private ZuulProperties zuulProperties;

    @Autowired
    private ServerProperties serverProperties;

    @Bean
    public DynamicZuulRouteLocator routeLocator() {
        DynamicZuulRouteLocator routeLocator = new DynamicZuulRouteLocator(
                serverProperties.getServlet().getContextPath(), zuulProperties);
        return routeLocator;
    }
}

刷新接口

@RestController
public class RefreshController {
    @Autowired
    private ApplicationEventPublisher publisher;
    @Autowired
    private RouteLocator routeLocator;
    @Autowired
    private ZuulHandlerMapping zuulHandlerMapping;

    @GetMapping("refreshRoute")
    public String refreshRoute() {
        RoutesRefreshedEvent routesRefreshedEvent = new RoutesRefreshedEvent(routeLocator);
        publisher.publishEvent(routesRefreshedEvent);
        return "refresh success";
    }

    @GetMapping("watchRoute")
    public Object watchNowRoute() {
        //可以用debug模式看里面具体是什么
        return zuulHandlerMapping.getHandlerMap();
    }
}
